Multiple Choice
In a right triangle, one leg has length , the other leg is labeled , and the hypotenuse has length . What is the value of ?
80
views
2. Trigonometric Functions on Right Triangles
Solving Right Triangles
2:29 minutesProblem 1
Textbook Question
The graph of a tangent function is given. Select the equation for each graph from the following options: y = tan(x + π/2), y = tan(x + π), y= -tan x, y = −tan(x − π/2).
Verified step by step guidance1
Identify the vertical asymptotes of the tangent graph. From the graph, the asymptotes are at \(x = -\frac{3\pi}{4}\) and \(x = \frac{\pi}{4}\).
Recall that the standard tangent function \(y = \tan x\) has vertical asymptotes at \(x = \pm \frac{\pi}{2}\), and the period is \(\pi\). The asymptotes in the given graph are shifted horizontally compared to the standard tangent function.
Determine the horizontal shift by comparing the asymptotes of the given graph to those of \(y = \tan x\). The asymptotes of \(y = \tan x\) are at \(x = \pm \frac{\pi}{2}\), but here they are at \(x = -\frac{3\pi}{4}\) and \(x = \frac{\pi}{4}\). This indicates a shift of \(-\frac{\pi}{4}\) to the left.
Use the horizontal shift to write the equation of the tangent function. A shift to the left by \(\frac{\pi}{4}\) means the function is \(y = \tan\left(x + \frac{\pi}{4}\right)\). However, this is not one of the options, so check if the function is reflected or shifted further.
Check the zeros of the function at \(x = -\frac{\pi}{4}\) and \(x = \frac{3\pi}{4}\), and compare with the options. By analyzing the behavior and the given options, conclude which equation matches the graph based on the shifts and reflections.
Verified video answer for a similar problem:This video solution was recommended by our tutors as helpful for the problem above
Video duration:
2mKey Concepts
Here are the essential concepts you must grasp in order to answer the question correctly.
Tangent Function and Its Graph
The tangent function, y = tan(x), has vertical asymptotes where the cosine function is zero, at x = ±π/2, ±3π/2, etc. Its graph repeats every π units, showing periodic behavior. Understanding the shape and asymptotes of the tangent graph is essential for identifying transformations.
Recommended video:
5:43
Introduction to Tangent Graph
Horizontal Shifts of Trigonometric Functions
A horizontal shift in the function y = tan(x + c) moves the graph left or right by c units. This shift changes the location of vertical asymptotes and zeros accordingly. Recognizing how shifts affect the graph helps match equations to their graphs.
Recommended video:
6:31Phase Shifts
Reflection of the Tangent Function
Multiplying the tangent function by -1, as in y = -tan(x), reflects the graph across the x-axis. This changes the direction of the curve between asymptotes but does not affect the location of asymptotes. Identifying reflections is key to distinguishing between similar tangent graphs.
Recommended video:
5:00Reflections of Functions
